※Operation explaining
First, pile up the old sand (or the own sand of casting after pouring) putting the screen mesh place , make the improving machine after shaking of sand rise to shake the screen mesh , separate the sand and incidental (such as the sand core , iron plate )?????? The sand powder uses the brute force (suck ) to collect the dust machine to collect .

Second, store the clean old sand in the sand barrel, control with time, send the ration of sand in the sand mixing machine with the conveyer belt (look at the capacity of the sand mixing machine and establish).

The package is stated and specification:?

First, store on the barrel?
It store this sand the barrels for storing the more own to screen into good recovery sand above combine there aren't device , take the dust , steam out with the profit, the side installs the controller of amount of sand had.

Second, shake and screen the network (the upper strata)
This equipment is divided into two layers and screened the network, the upper strata are 1 inch =4 eyes, the lower floor is 1 inch =6 eyes, and enclose and shake the motor, shake the sand to screen, it is damaged to use the screen mesh with the passing of time, it is easy to change, there is an incidental that retrieves the channel outside.

Third, improving machine
This device mainly promotes and sends sand and old sand after select thickly to and sifts the sand network to deal with.

Fourth, shake and screen the network (lower floor)
This equipment function is like the aforesaid, the function is to cast the incidental in the sand, for instance: Water each, casting iron, sand core and go ahead of the rest through straining, it is the first for a machine that screens the course.

Fifth, sand amount control the conveyer belt
This conveyer belt is in order to control the number of quantity, please cooperate and mix the specification content of the sand machine, do the proper benefit sand, and not excessive so as not to damage to and mix the sand machine.

Sixth, collect the dust machine
This equipment sets up the automatic dust and drops and waves the dust that the device needs to clear up the cloth while managing frequently in order to keep the good working environment.
